PG

A

Diagonal distance

B

Parallel plane distance

C Max

D Length

E Thickness

F Diagonal distance

G

Parallel plane distance

Cable outer diameter

Panel cutout

P/n Grey

P/n Black

7

16.5

15.5

19.2

8

5

21

19

3-6.5

13

PA807G

PA807B

9

21

19.5

21.6

8

5

24

22

4-8

15.7

PA809G

PA809B

11

24.7

22.7

24.7

8

5

27

24.6

5-10

19

PA811G

PA811B

13.5

26.5

24

26.6

9

6

30

26.9

6-12

20.5

PA813G

PA813B

16

30

27.3

28.8

9.8

6.5

33

30.2

10-14

22.5

PA816G

PA816B

21

36.5

19

28.8

12.1

6.7

38.4

35.8

13-18

28

PA821G

PA821B

29

47.3

33

31.3

11

7.3

50.5

46.2

18-25

37.2

PA829G

PA829B

36

59.2

53.2

50

12.8

7.7

65

59

22-32

47.8

PA836G

PA836B
