Material and spec
| Coupling Type | Bayonet Coupling |
| Shell | Plug:Nylon66 Socket:PC |
| Contact material | Brass with silver plating |
| Rated current(A) | 20 |
| Rated voltage(AC.V) | 250 |
| Test voltage(AC.V)1 min | 2500 |
| Insulation resistance MΩ | 2000 |
| Mating cycle | 1000 |
| Temperature range | -40℃~+85℃ |
| IP range | IP65 |
| Termination | Plug:screw,Receptacle:3/16" flat tab terminals |
